The following summarizes the Altium Gerber file extensions:ġ0 PCS, 10cm x 10cm, 2 layers prototype for $38.The most powerful, modern, and easy-to-use PCB design tool for professional use.

PROTEL 99SE GENERATE DRILL DRAWING ZIP

Then zip all files in the output folder and send to us for PCB fabrication. Rename the project output folder to something meaningful so you know what it is. Then in the PCB view, select File -> Fabrication Outputs -> NC Drill Files, in the NC Drill Setup dialog, select "Inches" for Units, "2:5" for Format, "Suppress leading zeros" for Leading/Trailing Zeros and "Reference to relative origin" for Coordinate Positions, then click OK:Īltium saves all generated Gerber and NC Drill files in the "Project output folder", usually it is in the same folder as your PCB project folder. You don't need to save the generate CAM file, just close it. Also select "Suppress leading zeros" for Leading/Trailing Zeros, select "Reference to relative origin" for Position on Film and select "Unsorted" for Plotter Type, then click OK:Īfter a few seconds, Gerber files are generated. In Advanced tab, select "Separate file per layer" for Batch Mode option. In Apertures tab, make sure RS274X is selected: In the Drill Drawing tab, deselect all check boxes, and select Graphic Symbols: Check "include unconnected mid-layer pads", and uncheck "Mechanical layers to Add to All plot": In Layers tab, select "Used On" for the Plot Layers drop down, select "All OFF" for Mirror layers. Then in the popup dialog, select General tab, set Unit to inch and format to 2:5: In PCB view, select File -> Fabrication Output -> Gerber files. If there are errors, you need to fix them before you can continue to generate Gerber files. Our PCB manufacturing capabilities are outlined at the home page of, please using Design Rule Wizard to modify the rules accordingly. DRC usually makes sure that your board doesn’t exceed the manufacturer’s production abilities. Make sure you run design rule check (Tools->Design Rule Check.) before you generate Gerber files. If not: winzip or winrar Export Gerber files from Altium Design rule check You need winzip or winrar, you probably already have it installed.

PROTEL 99SE GENERATE DRILL DRAWING HOW TO

In this tutorial, we are going to show you how to export Gerber files from Altium Designer (formerly known as Protel), so that you can send it to for PCB fabrication.
